DCA150AA60

Certifications title

Sanrex

Mosfet & Diode -> Soft Recovery Diode

Soft Recovery Diodes are designed with a ratio between the reverse recovery time (Trrr) and the current fall time (Trrf) of approximately 1:3. This structure ensures a smooth current transition during switching, helping to reduce voltage spikes caused by high current variations (dI/dt) in circuits with inductance, including parasitic inductances. Thanks to their soft recovery behavior, these diodes minimize electromagnetic interference (EMI) and enhance system reliability, making them ideal for use in converters, inverters, and switching power supplies.

Image	Code	Vrrm [V]	Ifa[A]	Tc [°C]	I2t	Ifsm	Vfm
	DBA100UA40 400V | 2X50A | 99°C | 1000A2s | 490A | 1,10V	400V	2X50A	99°C	1000A2s	490A	1,10V	POWER MODULE SOFT RECOVERY DIODE 400V 2x50A
	DBA200UA40 400V | 2X100A | 96°C | 2100A2s | 700A | 1,05V	400V	2X100A	96°C	2100A2s	700A	1,05V	POWER MODULE SOFT RECOVERY DIODE 400V 2x100A
	DBA200UA60 600V | 2X100A | 89°C | 2100A2s | 700A | 1,20V	600V	2X100A	89°C	2100A2s	700A	1,20V	Power Module Very Soft Recovery Diode 600V 2x100A
	DBA200WA40 400V | 2X100A | 96°C | 5050A2s | 1000/1100A | 1,10V	400V	2X100A	96°C	5050A2s	1000/1100A	1,10V	Power Module Soft Recovery Diode 400V 2x100A
	DBA200WA60 600V | 2X100A | 89°C | 2100A2s | 1000A | 1,25V	600V	2X100A	89°C	2100A2s	1000A	1,25V	POWER MODULE SOFT RECOVERY DIODE 600V 2x100A
	DBA200XA20 200V | 2X100A | 97°C | 5000A2s | 1000/1100A | 0,95V	200V	2X100A	97°C	5000A2s	1000/1100A	0,95V	Power Module Soft Recovery Diode 200V 2x100A
	DSR200BA 500V | 200A | 85°C | 45000A2s | 3300A | 1,20V	500V	200A	85°C	45000A2s	3300A	1,20V	POWER MODULE SOFT RECOVERY DIODE 500V 200A
	DCA100AA60 600V | 100A | 85°C | 16700A2s | 2000A | 1,18V	600V	100A	85°C	16700A2s	2000A	1,18V	POWER MODULE SOFT RECOVERY DIODE 600V 100A
	DCA150AA60 600V | 150A | 72°C | 26000A2s | 2500A | 1,18V	600V	150A	72°C	26000A2s	2500A	1,18V	POWER MODULE SOFT RECOVERY DIODE 600V 150A
